Frame
Blackthorn Alloy V1
-
Color
Dark Gray
-
Suspension fork
RockShox 35 Gold RL, 160 mm, 44 mm offset
-
Rear shock
RockShox Super Deluxe Select OR RockShox Deluxe Select+
-
Headset
FSA Orbit 1.5E NO.57E ACB, ZS44/ZS56
-
Seatpost
TranzX YSI05, Shimano MT500 lever, 30 mm travel adjust (SM 125 x 409 mm, MD 150 x 459 mm, LG 170 x 499 mm, XL 200 x 559 mm)
-
Stem
Salsa Guide Trail 50 mm
-
Grips/bar tape
Salsa File Tread Lock-on
-
Saddle
WTB Volt 250 Steel, 250 x 135
-
Handlebar
Race Face Chester 35, 780 mm width
-
Rear derailleur
Shimano Deore M6100 SGS
-
Cassette
Shimano Deore M6100, 10–51t, 12-speed
-
Chain
Shimano Deore M6100
-
Crankset
Shimano MT512, 30t
-
Shifter
Shimano Deore M6100
-
Brake levers
Shimano MT4100
-
Brake calipers
Shimano MT4100
-
Rotors
Shimano RT10, Center Lock (180 mm)
-
Front wheel
Shimano MT400-B 15 x 110 mm hub, WTB ST i30 29" rim
-
Rear wheel
Shimano SLX M7130 12 x 157 mm hub, WTB ST i30 29" rim
-
Front tire
Maxxis Assegai 29 x 2.5", Maxx Grip/Maxx Terra, EXO+, TR
-
Rear tire
Maxxis Dissector 29 x 2.4", Maxx Grip/Maxx Terra, EXO+, TR
-
Weight (Complete bike)
36 lbs 7 oz for Medium
-
Design wheel/tire sizes
29 x 1.9–2.6"
-
Alternate wheel/tire sizes
27.5 x 2.8–3.0"
-
Suspension fork length (travel)
140–160 mm
-
Fork offset
42–51 mm
-
Rear spacing
157 x 12 mm TA
-
Rear axle size
12 x 197 mm, TP = 1.75, TL = 20 mm
-
Rear brake (rotor)
74 mm post mount (180–203 mm)
-
Headset - Upper
ZS44
-
Headset - Lower
ZS56
-
Rear shock size
210 x 52.5 mm
-
Shock mount, fore
Ø8 x 30mm
-
Pivot kit
1215, 1585, 1587, 1589, 1590, 1592, 1594
-
Seatpost (diameter)
30.9 mm
-
Dropper post compatible
Yes (internal)
-
Seatpost clamp
35.4 mm
-
Max post insertion
SM = 195 mm, MD = 220 mm, LG = 245 mm, XL = 270 mm
-
Derailluer hanger
FS2322
-
Bearings
17287 (Qty 4), 6801 (Qty 6)
-
Bottom bracket
73 mm BSA, threaded
-
Crankset (Max ring)
Super Boost 157, 55–57 mm chainline (34t)
-
Accessory mounts
Top Tube Mounts: Compatible with Salsa EXP Series Direct Mount Top Tube Bag
-
Bottle mounts
1
-
Geometry measurement basis
an unsprung bike (no sag), a 29 x 2.4" tire measuring 746mm in diameter, Standover is measured from vertically from ground to top of top tube 50mm forward of bottom bracket, subtract 9mm (0.3") for 27.5 x 2.8" tires, Note: Where two measurements are listed, the first number is with Flip Chip in Low position; the second number is with Flip Chip in High position
-
Geometry - Effective Top Tube (Small)
594.0 - 593.0
-
Geometry - Effective Top Tube (Medium)
616.0 - 615.0
-
Geometry - Effective Top Tube (Large)
640.0 - 639.0
-
Geometry - Effective Top Tube (X-Large)
663.0 - 662.0
-
Geometry - Stand Over (Small)
726.0 - 728.0
-
Geometry - Stand Over (Medium)
729.0 - 732.0
-
Geometry - Stand Over (Large)
730.0 - 733.0
-
Geometry - Stand Over (X-Large)
730.0 - 733.0
-
Geometry - Reach (Small)
448.0 - 451.0
-
Geometry - Reach (Medium)
469.0 - 472.0
-
Geometry - Reach (Large)
490.0 - 493.0
-
Geometry - Reach (X-Large)
510.0 - 514.0
-
Geometry - Stack (Small)
611.0 - 609.0
-
Geometry - Stack (Medium)
615.0 - 613.0
-
Geometry - Stack (Large)
624.0 - 622.0
-
Geometry - Stack (X-Large)
633.0 - 630.0
-
Geometry - Total Seat Tube Length (Small)
405.0
-
Geometry - Total Seat Tube Length (Medium)
430.0
-
Geometry - Total Seat Tube Length (Large)
455.0
-
Geometry - Total Seat Tube Length (X-Large)
480.0
-
Geometry - Headtube Length (Small)
95.0
-
Geometry - Headtube Length (Medium)
100.0
-
Geometry - Headtube Length (Large)
110.0
-
Geometry - Headtube Length (X-Large)
120.0
-
Geometry - Headtube Angle (All Sizes)
64.6 - 64.9
-
Geometry - Seat Tube Angle (All Sizes)
76.5 - 76.8
-
Geometry - BB Drop (Small)
26.0 - 22.0
-
Geometry - BB Drop (Medium)
26.0 - 22.0
-
Geometry - BB Drop (Large)
26.0 - 21.0
-
Geometry - BB Drop (X-Large)
26.0 - 21.0
-
Geometry - Chainstay Length (All Sizes)
432.0 - 431.0
-
Geometry - Fork Length Axle to Crown (All Sizes)
569.0
-
Geometry - Fork Offset (All Sizes)
43.0
-
Geometry - Wheelbase (Small)
1204.0 - 1204.0
-
Geometry - Wheelbase (Medium)
1228.0 - 1227.0
-
Geometry - Wheelbase (Large)
1253.0 - 1252.0
-
Geometry - Wheelbase (X-Large)
1278.0 - 1278.0
-
Geometry - Crank Arm Length
Small: 165.0, Medium: 170.0, Large: 170.0, X-Large: 175.0
-
Geometry - Stem Length (All Sizes)
50.0
-
Geometry - Recommended Rider Height
Small: 165.0 - 173.0, Medium: 173.0 - 180.0, Large: 180.0 - 188.0, X-Large: 188.0
